MSD Pro 600 Ignition Boxes

Product Info

The MSD Pro 600 CDI ignition box is an eight-channel capacitive discharge ignition comprehensively engineered to accommodate high cylinder pressure and high-horsepower engines running a coil-near-plug ignition. The PRO 600 is efficient in converting any distributor type ignition into a coil-near-plug system. By reliably providing outstanding spark energy and dependability, the PRO 600 CDI ensures horsepower isn’t compromised when you’re making extreme cylinder pressure with boost or nitrous on an inductive coil-per-plug ignition.

For emergency purposes, these ignition boxes feature a built-in defense system for accidental reverse battery connection along with over-temperature protection and LED diagnostics that detect issues with individual coils. Through an activation wire or software, race enthusiasts can integrate a programmable power setting to alter between an adjustable 250 to 400 millijoule output or an industry-leading 680 millijoules output. The PRO 600 offers continuous 600 mJ operation without the possibility of faltering due to overheating. What’s more, its excellent alternating current power delivery ensures less voltage draw from the battery or charging system.

Features:

• Made from High-Quality High-Impact Materials for Durability
• Guaranteed MSD Craftsmanship
• Eight Outputs of Up to 680 Megajoule of Energy
• Continuous 600 Megajoules Operation Without Risk of Failure from Overheating
• High-Efficiency Alternating Current (AC) Power Delivery Means Less Voltage Draw from Your Battery or Charging System
• With Over 50 Kilovolts Output Voltage When Used With MSD Suggested Coils
• Spark Duration of Greater Than 300 Microseconds
• With 6 Volts Minimum Required for Starting and Running
• With 12 Volts Minimum Required for 600 Megajoules Operation
• Maximum Operating Voltage 22 Volts
• Direct Plugin to Holley EFI Systems
• Compatible With Most EFI Systems, Including 5 Volts or 12 Volts Drivers
• Plugin Interface With MSD Power-Grid, Davis Profiler and OEM LS-Style Coil Harness
• Reverse Battery Protection
• Comes With Protection Against Shorted or Open Coils, and Over Temperature
• Diagnostic LEDs Help Troubleshoot Issues Should They Arise
• On the Fly Power Output Selection Wire, Selectable Between Low Power and High Power Operation
• Fits Most Coil-Per-Plug Engines Up to Eight Cylinders (Including Four and Six Cylinders)
• Additional CAN Based Features When Used With Holley EFI
• Includes All Necessary Wiring Harnesses
• Approved For NHRA Pro Mod Class
• Designed to Meet or Exceed Factory Standards
• Built to Last

Established in 1970, MSD is a highly-regarded developer and manufacturers of top-quality ignition controls, distributors, ignition coils, and other essential accessories that aim to optimize the functionality of an ignition system. Whether it be super speedways, road courses, land speed racing, conventional hot rods, or any other motorsports application, MSD has always found the means to produce the precise parts and accessories that shape the way a vehicle performs. The company is reliable when it comes to products that work and communicate together to ensure maximum performance and excellent value.

As the engineers responsible for the first multiple-spark discharge ignition control box, MSD consistently evolves and provides the most progressive in performance ignition technology. The company continues to adapt and expand to accommodate the needs of the time, creating upgrades that exceed expectations and are easy to install. Regardless of the challenges and competitions your engine faces, the inimitable performance products by MSD are sure to be the ideal solutions for a dominant victory.
